Two-speed column polishing machine with electrically-operated raising and lowering. System with pneumatic piston and pressure adjustment for polishing marble and granite, or for brushing or rotary bush hammering with plate.
MANUAL POLISHER MTP
MANUAL POLISHER MTP
- extremely thick cast iron base to guarantee necessary rigidity and resistance to potential vibrations
- extremely thick hardened and tempered steel column to guarantee precision movement, protected by bellows cover
- rear arm connected to the column on one side and to the other arm, by way of a hinge, on the other side; it is raised or lowered by way of a lifting screw coupled to a safety nut attached to it; the sliding column can also be adjusted
- front arm with function of supporting the spindle and its transmission
- manual pump located on front-left side to lubricate sleeve and spindle
Below are the technical characteristics of the MTP model:
| Spindle motor power | 4,5/5,5 KW |
| Spindle revolutions | 500/1000 Giri/min |
| Spindle lifting cylinder stroke | 100 mm |
| Lifting stroke | 300 mm |
| Work capacity | 400x3500x1400x2500 mm |
| Maximum radius | 2000 mm |
| Machine weight | 800 Kg circa |
